Metrum Forte™

€2,834.13 Save 30%
€4,048.76

The Metrum Forte power amplifier will serve you without problems as known with normal hybrids but still having the holographic sound as known from good tube designs.

Color
Voltage
Quantity

For a long time Metrum Acoustics has used hybrid (triode) amps for pleasure listening and critical evaluations. What we did not like was the fact that triodes suffer aging problems. In simulation software, we started to simulate triodes with fets instead. The good thing with triodes is their low gain and a lot of bandwidth without any need for feedback. As a result we realized a full class A high voltage fet circuitry having the right gain, very good open loop bandwidth  and low noise figures. A similarity is the high voltage of 350 Volts to get this circuit running. As a result an amazing linearity without any feedback was realized. From this point the circuit  is driving a class A/B output section (10 watts in class A). Some little feedback is necessary to get the right gain but also improves the damping factor at the same time . Compared to our old hybrids, there’s no sonic difference, just less noise and lower distortion.

After two years of prototyping and testing, we’ve now turned this into a commercial product. The circuits are quite over-dimensioned to be sure that no errors occurs. Still we added  a lot of protection to avoid any damage to your loudspeakers in case of malfunction. A soft start procedure is added to charge the amazing capacity of 176000µF. This huge capacity is available during complex and dynamic transients. As known hybrids combine tube sound and amazing control as realized by transistor designs. Here you have the solution. The Metrum Forte power amplifier will serve you without  problems as known with normal hybrids but still having the holographic sound as known from good tube designs. The Forte is an addition to our awarded Adagio or Jade digital pre-amplifier.



Non EU? Tax will be excluded after entering delivery address on checkout.

Data sheet

Amplifier class:
Class A.
Power:
50 Watt to 8 Ohm, 100 Watt to 4 Ohm, 170 Watt to 2 Ohm.
Max power 400 Watt.
Total harmonic distortion:
0.03% THD.
Damping factor:
200.
Output noise:
300 µV RMS.
Slew rate:
50V / µSec.
Frequency response:
10-90.000 Hz – 3DB.
Input sensitivity:
RCA 240 mV RMS for 1 Watt, 1.75 V for 50 Watt, XLR 480 mV RMS for 1 Watt, XLR 480 mV RMS for 1 Watt, 3.5 V for 50 Watt.
Input impedance:
RCA 15 KOhm, XLR 60 KOhm.

Download

Metrum Forte User Manual

Metrum Forte User Manual

Download (659.86KB)
